GENERATOR 6KW
MACHINE TECHNICAL SPECIFICATIONS:
Working area: 3048x1524 mm
Maximum movement speed: 200 m/min
Z-axis travel: 315 mm
X/Y positioning accuracy: +0.05 mm
X/Y repositioning accuracy: +0.03 mm
Maximum acceleration: 4 G
Maximum worktable load capacity: 1450 kg
Worktable functions: Easy-access sliding bed
Laser source: Bodor Power 6 kW
Servo motor and driver: Yaskawa (Japan)
Fan: 1 set
Chiller: 1 set
Automatic nozzle changer: 8 positions
Automatic nozzle cleaning: Standard equipment
Bodor Nesting software: Standard equipment
Cutting capacity: Iron 25 mm; Stainless steel 25 mm; Aluminum 15 mm
Dimensions: 9950x3050x2300mm
Total machine weight: 7,500kg
MACHINE EQUIPMENT:
-One-click process
-BODOR lightening perforation
-Mortise-and-tenon welded bed structure
-Extended aluminum beam
-Auto-Focus
-Scanning laser cutting system
-Bodor Thinker operating system
-Quick pallet change (10s)
-Cutting parameter database
-Anti-vibration system for thin sheets
-Constant flow nozzle for gas savings
-Intelligent maintenance alarm
-WIFI control: remote diagnosis and monitoring of machine and laser source problems
-Automatic adjustment of cutting gas pressure (O2, N2, and air)
-Safety system with automatic detection of human presence around the machine
EQUIPPED WITH:
-Fuel filtration system
-Cutting head with laser scanning system

USED MACHINE
YEAR 2023

IMAGES:
