SLOTTING EASTAR MOD.TS-350K
slotting - Used Machines
EASTAR
09791
09791
Max stroke 350 mm
Table diameter 560 mm
Longitudinal table stroke 500 mm
Cross table stroke 520 mm
Beating piston speed 28,50,80,105 strokes per minute
Distance between head and table surface 330 mm
Motor power Hp 3-3 phase, 4 pole
Net weight 2000 kg
Overall dimensions 2000x1100x2000 mm
USED MACHINE
FILL OUT OUR FORM FOR MORE INFORMATION
