WIRE ERODER ONA AE-400
Wire
edm electro discharge machines - Used Machines
ONA
09654
09654
X stroke mm 600
Y stroke 400 mm
Z stroke 400 mm
U - V stroke 80 mm
Max piece dimensions (X,Y,Z) mm 1000x810x400
Max piece weight 3000 kg
Conical cutting angle +/-5°/400 mm
Max conical cutting angle +/- 30°/50 mm
Wire diameter 0.1-0.30 mm
Min. adjustable increment (X,Y,U,V) mm 0.001
Min. programmable increment 0.001 mm
Weight 3900 kg
USED MACHINE
YEAR 2007
IMAGES:
FILL OUT OUR FORM FOR MORE INFORMATION
