HORIZONTAL CENTER MAZAK H-1250
Double pallet
machine center - horizontal - Used Machines
MAZAK
07431
07431
Pallet dimensions mm 1250x1250
Axis X stroke mm 2000
Axis Y stroke mm 1500
Axis Z stroke mm 1200
Distance between spindle to table center mm 350-1550
Distance between spindle center to table plane mm 50-1550
Rapid feed axis X e Y mt/min 15
Rapid feed axis Z mt/min 12
Spindle speed rpm 20-4000
Spindle taper DIN 69871 50
Table load Kg 4000
Tool change 120 positions
Tool lenght mm 600
Tool width mm 130/260
Tool weight Kg 30
Tool changing time chip-chip sec 20
Overall dimensions mm 4750x6300x4255H
Weight Kg 30.000
USED MACHINE
FILL OUT OUR FORM FOR MORE INFORMATION
